Feature 1:Supports fast transfer rate of up to 6 Gbps *1

World’s first to support a transfer rate of 6 Gbps, enabling high-speed processing.

Feature 2:Multiple copy modes (and compare functions)

Examples: Physical (full) copy/ copying of specific data volume/ logical (file) copy*2/ expand copy*3

Feature 3:Supports all interfaces *4

Examples: SAS / SATA / IDE / SCSI / FC

Feature 4:Cross copy capability between different interfaces

Feature 5:Has error skipping function

Will skip bad sectors to force backup

Feature 6:Volume clip function

Enables you to specify DD volume

*1: Options available with DE-320, DE-330
*2 : Supports FAT32, NTFS3.0/3.1, Ext2, Ext3 file systems
*3: Supports NTFS3.0/3.1 file system
*4: Options vary by product

For kitting operations in corporate information systems departments or IT product manufacturers!
For creation of backups from IT products or products incorporating HDDs by maintenance/service departments!

Feature 1:Automatically generates a log showing results of erasure

The log is stored on flash-ROM built into the unit. High-volume log data can also be stored on an external USB memory *5.
Examples: Drive name/ serial number/ drive capacity/ information on erasure start and finish times

Feature 2:All models come with software to generate erasure certificates as standard feature

You can use the erasure log data to print a certificate via a special PC tool.

Feature 3:Supports numerous erasure methods as a standard feature

Examples: NSA/ DoD/ all zeros/ N overwrites

Feature 4:Read-out check function

After data wiping by the relevant method, you can verify by checking the completeness and quality of the erasure.

For server and storage-device erasure services during field-support operations!
For the erasure operations of information systems departments, lease/rental operators and suppliers of used equipment!

Feature 1:Tests the basic functions of different HDDs

Examples: Read / write / write and read / write and compare / compare

Feature 2:User can choose the access method and transfer block size

Examples:Sequential / random access

Feature 3:Other processing conditions can be changed

Examples: Testing time/ number of iterations/ writing pattern/ diagnostic coverage

Feature 4:Can read out S.M.A.R.T. information for checking (diagnosis)

For use in HDD testing and performance checking by IT maintenance support and system management departments!
For testing of HDDs prepared for users by kitting departments!

Feature 1:Generates and compares hash values

Examples: MD5 / SHA1 / SHA256

Feature 2:Can generate a graphic representation of DD

The DD graphic data generated can be stored on a PC using a special tool

Feature 3:Supports various different HDD interfaces

Examples: SAS / SATA / IDE / SCSI / FC interfaces

*1: Options available with the DE-320 and DE-330
*2: Supports FAT32, NTFS3.0/3.1, Ext2 and Ext3 file systems
*3: Supports NTFS3.0/3.1 file system
*4: Options vary by product
*5: Options supplied with the product at the time of shipping.
*6: Optional forensic analysis software is required to perform analyses.

For maintenance of forensic data by legal departments and organizations handling impounded property!
For preservation of evidence by information security departments of government agencies and corporations!
